Khoom Description

Lub extruder, lub tog raj kheej thiab ntsia hlau ntawm HDPE zaj duab xis tshuab tshuab yog ua los ntawm cov hlau zoo hlau. Tom qab nitriding thiab precision machining, lub hardness yog qhov zoo tshaj plaws thiab corrosion kuj muaj zog, uas yog tshwj xeeb tsim screws txhim khu lub plasticization ntawm zaj duab xis thiab pab txhawb kev tsim khoom.

HDPE zaj duab xis tshuab tshuab yog tsim rau lub tshuab tshuab yas xws li low density polyethylene (LDPE), high density polyethylene (HDPE) thiab linear low density polyethylene (LLDPE). Nws yog dav siv hauv kev tsim khoom noj, khaub ncaws, khib nyiab thiab lwm yam ntim khoom ntim.

Main Technical Variables:

Qauv	SJ-50/FM600	SJ-55/FM800	SJ-60/FM1000
Ntsia Hlau Diameter	50 hli	55mm ua	60 hli
Ntsia Hlau Ratio	L/D30:1	L/D30:1	L/D30:1
Ntsia Hlau Ceev	10-150r/min	10-150r/min	10-150r/min
Lub zog ntawm Main Motor	22 kWm	30 KW	37 kWm
Extrusion tso zis	30-70kg/h	40-100kg/h	50-150kg/h
Max. Folding dav ntawm zaj duab xis	600 hli	800 hli	1000 hli
Ib sab Thickness ntawm zaj duab xis	0 008-0.10mm	0 008-0.10mm	0 008-0.10mm
Sub-master Machine Lift Scope	800 hli	1000 hli	1200 hli
Tag Nrho Lub Zog	32 kwv	44 kwv	49 kwv
Qhov hnyav ntawm lub tshuab	2600kg ib	3000 kg	3500kg ib
Zuag qhia tag nrho Dimension	4600 * 2600 * 4000mm	4800 * 2800 * 4300 hli	5000 * 3000 * 4800mm

Nta:

* Tsis siv neeg tswj, hloov kho cua sov, yooj yim rau kev khiav lag luam.

* Cov cuab yeej traction yog stepless ceev tswj, dav ceev ntau, ruaj khov thiab txhim khu kev qha.

* Kev xaiv ob npaug ntawm cov yeeb yaj kiab ntug, kev sib txhuam ob chav winding, winding zoo zoo, yooj yim hloov yob.

* Hnav-resistant, corrosion-resistant, tsis siv neeg kub tswj, raug thiab txhim khu kev qha, siv kev sib txhuam ob-yob mechanism, tsis siv neeg metering, yooj yim rau kev khiav lag luam.

* Lub fuselage yog channel steel thav duab, thiab lub ntsiab cav yog nruab nrog ib tug qis-center iav reducer, uas muaj qhov zoo ntawm kev ruaj ntseg kis tau tus mob, loj torque thiab yooj yim txij nkawm.

* Lub thoob thiab ntsia hlau yog ua los ntawm cov hlau alloy, uas yog nitrided, tawv thiab siab, nrog zoo corrosion kuj thiab kav ntev.

Daim ntawv thov

Ntim Cov Khoom: HDPE zaj duab xis yog siv dav hauv cov ntawv ntim khoom, xws li tsim cov hnab yas, hnab, thiab cov hnab ntim khoom. Cov yeeb yaj kiab no muab kev tiv thaiv rau cov khoom ntim khoom thiab tuaj yeem siv rau kev ntim khoom noj, ntim khoom lag luam, hnab khw muag khoom, thiab lwm yam.
Agricultural Films: HDPE zaj duab xis yog siv rau hauv kev ua liaj ua teb rau ntau lub hom phiaj, nrog rau lub tsev cog khoom npog, mulch films, silage hnab, thiab cov qoob loo tiv thaiv npog. Cov yeeb yaj kiab pab tswj lub teeb, qhov kub thiab txias, thiab noo noo, txhawb kev cog qoob loo zoo.
Kev tsim cov yeeb yaj kiab: HDPE zaj duab xis yog siv rau hauv kev tsim kho rau cov ntawv thov xws li vapor barriers, cov ntaub ntawv pov thawj noo noo, thiab cov npog tiv thaiv ib ntus. Lawv pab tiv thaiv kom tsis txhob ya raws infiltration thiab tiv thaiv cov khoom siv los ntawm cov khoom.
